100AH Group Size: 27 (13"x 6.8"x 9")
200AH Group Size: 4D (20.5"x 10.6"x 8.7")
300AH Group Size: 4D (20.5"x 10.6"x 8.7")
Cycle life: 2000+ cycles at 80% discharge depth
Rated voltage: 12.8V
Charge voltage: 14.2 - 14.6V
Depth of Discharge (DoD): 100%
Standard charge current: 30A
Charging time: Approximately 4 hours
Max continuous charge current: 50A
Max continuous discharge current: 100A
Peak discharge current: 300A (Duration: less than 3 seconds)
Operating temperatures: Charge -35°C~50°C(-31℉~122℉),
Discharge -20°C~60°C(-4°F~140°F), Storage -20°C~50°C(-4°F~122°F)
Impedance: ≤ 10mΩ
Mobile APP to read battery data: Compared with the traditional battery monitor, These smart lithium battery can directly communicate with the battery management system (BMS) and obtain various data (SOC) of the lithium iron phosphate battery. Customers can connect to the battery through the mobile phone APP, and read the battery voltage, current, battery capacity and other important information at any time. Wireless connection range: within 5-10 meters from the battery.
Heating Function: Only when the battery starts to charge, the heating function inside the battery can be turned on. When the ambient temperature is lower than 32°F (0°C), the charging current will only supply power to the heating film inside the battery. When the internal temperature of the battery reaches 50°F (10°C), BMS will immediately turn off the heating function, all the charging current charges the battery. The charging current of the low temperature heating battery is at least 5A.
Lithium Iron Technology: Lithium ion batteries have exceptional longevity since they manufacturing by Automotive Grade LiFePO4 Cells with higher energy density, more stable performance & greater power, letting you use the battery more freely. Our batteries are more cost effective, so when factoring time and cost into your purchase, our lithium ion battery banks come out ahead every time. It can support fast charging and solar panel charging.
Built-In BMS & Convenience & Maintenance Free: Our LiFePO4 battery has built-in BMS (Battery Management System) to protect it from overcharge, over-discharge, over-current, and short circuit with excellent self-discharge rate. Built-in high temp cut off prevents charging over 122 °F (50 °C). Plus, Li-Ion batteries can be safer than Lead Acid batteries, which have no protection against ground faults. Highest-level safety based on UL Testing Certificate for the cell inside the battery pack.
